Cable Type 1
2 twisted pair unshielded CAT 5, Belden #1588(A,R)
2 twisted pair unshielded CAT 5, Belden #1590A
Max Distance
for Cable (feet)
Max Distance for
Cable (meters)
Number of
SR 4 Remotes
Vs = 15V
RPM 44
RPM 22
1000 305 1
1000 305 2
769 235 3
599 183 4
490 149 5
415 126 6
359 110 7
317 97 8
Vs = 12V
RPM 88
1000 305 1
672 205 2
481 147 3
374 114 4
306 93 5
259 79 6
225 68 7
198 60 8
Vs = 8V 224 68 1
134 41 2
96 29 3
75 23 4
61 19 5
52 16 6
45 14 7
40 12 8
Note: This table is only for systems using SR 4 remotes (all remotes on 485 bus are
the same). For mix and match calculation of SR 2, SR 3 and SR 4 Remotes, use the
SRCABLELENGTH.XLS Microsoft Excel™ spreadsheet on the Drag Net CD-ROM or
at www.rane.com/sr4.html.
Requires
external
supply
