13-6
User Guide for Cisco Unified Operations Manager
OL-19470-01
Chapter 13 Generating Audio Phone and Video Phone Reports
Using Audio Phones and Applications Reports
For example, if you enter two phone models, such as 7910 and 7935, in the IP Phone Model field, the
Inventory Analysis report that results includes all phones of these models. If, in addition, you enter a
VLAN ID and a switch, Inventory Analysis searches for phones that meet all these criteria; the report
that results includes only phones of the models specified that are connected to the switch and in the
VLAN that you selected.
Step 1 Select Reports > Audio Phones and Applications > Inventory Analysis. The Find IP Phones page
appears.
Step 2 Enter values in one or more fields, described in the following table.
GUI Element Description/Action
Find IP Phones
Where list boxes and
field From left to right:
• Select one of the following:
– Extension number
– IP Address
– MAC Address
• Select one of the following:
– is exactly
– begins with
– contains
– ends with
• Enter a value.
VLAN Name field Enter the name of the VLAN.
VLAN ID field Enter the VLAN ID.
IP Phone Outage
status radio buttons Select one:
• Registered
• Unregistered
• All—Registered and unregistered phones.
SRST radio buttons Select one:
• SRST—Configured to fail over to an SRST router in case of a WAN link
failure.
• Non-SRST—Not configured for SRST.
• All—SRST and non-SRST.
Protocol radio
buttons Select one:
• SCCP—Phones using Skinny Client Control Protocol.
• SIP—Phones using Session Initiation Protocol.
• All—SCCP and SIP.
