13-39
User Guide for Cisco Unified Operations Manager
OL-19470-01
Chapter 13 Generating Audio Phone and Video Phone Reports
Using Video Phones Reports
Table 13-10 Video Phone Reports
Columns and Buttons Description/Action
Number The row number; starting from 1.
Check box Select phones that you would like to:
• Print—Include selected phones in a new window in print-friendly
format. (See
Phones Report Tool Buttons, page 13-13 .)
• Export to a file—Include selected phones in a PDF or CSV file. (See
Phones Report Tool Buttons, page 13-13 .)
• Launch a test on—Include selected phones in tests that you create
from the Launch button when it is present at the bottom of the report.
(See
Launching Tests for Selected Audio Phones, page 13-18 .)
Extn. Extension number of the video phone; for example, 4000. Click the
hyperlink to see more details of the video phone (see
Opening an IP Phone
Web Interface, page 13-18 ).
User Username obtained using LDAP if you have configured an LDAP server
in Operations Manager. See
Configuring LDAP, page 16-43 and Obtaining
Usernames from LDAP for IP Phone Reports, page 13-18 .
IP Address IP address of the video phone; for example, 10.76.38.65. Click the
hyperlink to see more details of the video phone (see
Opening an IP Phone
Web Interface, page 13-18 ).
MAC Address MAC address of the video phone; for example, 003094c40454, or
00-30-94-c4-04-54. Click the hyperlink to see more details of the video
phone (see
Opening an IP Phone Web Interface, page 13-18 ).
Model Model number of the video phone.
Protocol Protocol the phone is using to communicate with Cisco Unified
Communications Manager or Cisco Unified Communications Manager
Express.
Note Only SCCP and SIP phones will be discovered. H.323 and MGCP
protocols are not currently supported.
Regd. Registration status of the video phone with respect to Cisco Unified
Communications Manager or Cisco Unified Communications Manager
Express. Displays yes if the video phone is registered or no if the video
phone is not registered.
CCM One of the following:
• CCM—Cisco Unified Communications Manager.
• CCE—Cisco Unified Communications Manager Express.
CCM/CME Name DNS name of the Cisco Unified Communications Manager or Cisco
Unified Communications Manager Express with which the video phone is
registered.
CCM/CME Address IP address of the Cisco Unified Communications Manager or Cisco
Unified Communications Manager Express with which the video phone is
registered.
Switch Name Name of the switch to which the video phone is connected.
