13-38
User Guide for Cisco Unified Operations Manager
OL-19470-01
Chapter 13 Generating Audio Phone and Video Phone Reports
Using Video Phones Reports
Generating the SRST Video Phones Report
The SRST Video Phones report shows a list of phones that are configured for Survivable Remote Site
Telephony (SRST).
Step 1
Select Reports > Video Phones > SRST Video Phones. The SRST Video Phones report appears in a
new window, displaying information for the SRST configuration only. For more information, see
Understanding Video Phone Reports, page 13-38
.
Generating the SIP Video Phones Report
The SIP Video Phones report shows a list of SIP video phones.
Step 1
Select Reports > Video Phones > SIP Video Phones. The SIP Phones report appears in a new window,
displaying information for SIP video phones only. For more information, see
Understanding Video Phone Reports
describes the data displayed in the following reports:
•
Inventory Analysis—Includes phones that match criteria that you specify.
•
All Video Phones/Lines—Includes all video phones, including video phones that are configured for
SRST.
Note
You can filter the All Video Phones/Lines report to include only the phones that you want to
see.
•
SRST Video Phones—Includes only phones that are configured for SRST.
•
SIP Video Phones—Includes only SIP video phones.
By default, these reports display only these columns: Extension, User, IP Address, MAC Address,
Model, Regd, CCM, Switch Address, and Port. You can hide these columns and select among additional
columns to display. See
Selecting Columns to Display and to Hide on a Phone Inventory Report,
describes all possible columns of data that can appear on the reports.
Switch Address
IP address of the switch to which the video phone is connected.
Port
Switch port used by the video phone; for example, Fa0/12.
Table 13-9
TelePresence Report (continued)
Columns and Buttons Description/Action
