Page 32
32
Table 14—48HJ Outdoor Sound Power (Total Unit)
UNIT
48HJ
ARI
RATING
(decibels)
OCTAVE BANDS
63
125
250
500
1000
2000
4000
8000
004,005
76
55.9
66.0
64.0
66.2
68.4
64.5
61.7
57.3
006,007
80
59.1
68.9
68.7
71.9
74.0
68.9
65.7
59.0
LEGEND
ARI --- Air Conditioning and Refrigeration Institute
Table 15—48HE Outdoor Sound Power (Total Unit)
UNIT
48HE
ARI
RATING
(decibels)
A--
WEIGHTED
(db)
OCTAVEBANDS
63
125
250
500
1000
2000
4000
8000
003--005
76
76
55.9
66.0
64.0
66.2
68.4
64.5
61.7
57.3
006
80
80
59.1
68.9
68.7
71.9
74.0
68.9
65.7
59.0
GENERAL FAN PERFORMANCE NOTES
1. Values include losses for filters, unit casing, and wet coils. See Table 31 and Fig. 44 for accessory/FIOP static pressure information.
2. Extensive motor and electrical testing on these units ensures that the full range of the motor can be utilized with confidence. Using the
fan motors up to the ratings shown will not result in nuisance tripping or premature motor failure. Unit warranty will not be affected.
See Tables 9 and 10 on this page for additional information.
3. Use of a field-supplied motor may affect wire sizing. Contact your Carrier representative to verify.
4. Interpolation is permissible. Do not extrapolate.
Table 16—Fan Performance 40HE003 — Vertical Discharge Units; Standard Motor (Belt Drive)**
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.1
0.2
0.4
0.6
0.8
1.0
Rpm
Bhp
Rpm
Bhp
Rpm
Bhp
Rpm
Bhp
Rpm
Bhp
Rpm
Bhp
600
500
0.08
531
0.08
607
0.14
713
0.21
788
0.29
878
0.37
700
529
0.09
567
0.09
633
0.16
739
0.24
816
0.32
902
0.41
800
547
0.1
592
0.12
660
0.19
761
0.27
845
0.37
937
0.47
900
570
0.13
620
0.14
691
0.22
793
0.32
870
0.42
957
0.53
1000
599
0.15
650
0.16
717
0.26
818
0.36
894
0.47
981
0.58
48H
E,
H
J
