Configuration
About CP 100 and CP 200 connectivity software modules
The cardiopulmonary connectivity software comprises a set of modules that are installed
separately as needed. The modules related to CP100 and CP200 connectivity are listed
here:
Firewall settings
If you are using a firewall between any PCs in your CardioPerfect configuration, the
following ports or application files are required to gain access through the firewall.
Software installation automatically opens these ports.
Module Full name Description Installation location
CPSAPI CardioPerfect
Server
Application
Programming
Interface This is the database connectivity module. It plays a
central role, directing communications between
various software modules and the CardioPerfect
database. One CPSAPI per site
DC Data Catcher For CP 200 only. This module passes data to and
from the electrocardiograph(s). One DC per CPSAPI installation
and per Workstation that supports
wired-USB
DCP Device
Communication
Protocol For CP 200 only. This module listens for
electrocardiograph(s) that are connected
wirelessly, and it tells them which IP address
to communicate with. One DCP per subnet
FI File Importer This module receives tests from removable media
(SD memory cards or USB storage devices). One FI per Workstation receiving
tests via removable media
Software module Port Type Application file
CPSAPI 9247 TCP CPWS.Service.exe
DCP 44435 UDP DCPd.exe
DC 281 TCP DataCatcher.exe
CP 200 ICMP Allow incoming
echo requests Ping test
