12 Installation Welch Allyn cardiopulmonary connectivity software
The following screen appears:
6. Go to File > Options. You will see the following options:
You will normally not need to worry about the directory settings for incoming and
imported ECG tests unless your system administrator indicates those should reside
somewhere other than in the default folder.
By default, the COM port options will be set to port COM1 and a baud rate of 115200.
You can configure the AT-2 Plus for a baud rate of 115200 by pressing ALT-0-9-1-0 on
the AT-2 Plus. Please refer to the AT-2 Plus device manual for instructions on how to
set a different baud rate should that be required.
Finally, indicate to the AT2WACP program if your AT-2 Plus is configured for entry of
US measurements or not. By putting a check mark in the check box, you indicate that
inches and pounds will be expected. Remove the check mark if you enter
centimeters and kilograms on the AT-2 Plus.
List of any ECG tests that
failed to import correctly.
Action buttons for failed tests
Activity log
