74 Alarms and limits Welch Allyn Propaq Encore Vital Signs Monitor
Setting alarm limits
Adjust limits with STAT SET
When you want to quickly set all alarm limits, the Propaq Encore can calculate new alarm
limits using the patient’s current values. Press the STAT SET button in the Alarms Menu
(SETUP, ALARMS, STAT SET). The Propaq Encore activates all alarms and calculates the
limits for all monitored vital signs, except apnea delay. The monitor performs a
mathematical function (addition, subtraction, or multiplication) on the current value of the
vital signs to arrive at the new limits. The formulas for these calculations are shown in the
table.
Vital sign If the patient’s vital sign
value is Then calculated new lower
limit is Then calculated a new upper
limit is
a. New alarm limits calculated by STAT SET cannot be outside the allowable alarm limit range. If a new limit is calculated to be above
or below the allowable alarm limit range, it defaults to the maximum or minimum alarm limit allowed for that vital sign.
Heart Rate HR  99
100-250
HR
 251
HR x 0.8
HR - 20
Unchanged HR x 1.2
HR + 20
250
Pulse Rate PR
 99
PR
 100
PR x 0.8
PR - 20 PR x 1.2
PR + 20
Invasive
Pressure Inv Prs
 25
26 - 99
Inv Prs
 100
Inv. Pressure - 5
Inv. Pressure x 0.8
Inv. Pressure - 20 Inv. Pressure + 5
Inv. Pressure x 1.2
Inv. Pressure + 20
NIBP NIBP
 25
26 - 99
NIBP
 100
NIBP - 5
NIBP x 0.8
NIBP - 20 NIBP + 5
NIBP x 1.2
NIBP + 20
Respiration Rate/
Breath Rate RR/BR
 25
26 - 99
RR/BR
 100
RR/BR - 5
RR/BR x 0.8
RR/BR - 20 RR/BR + 5
RR/BR x 1.2
RR/BR + 20
Temperature Temp
 0°C
Temp - 0.5 Temp + 0.5
SpO
2
SpO
2
 0%
SpO
2
- 5
(min. limit 50%)
100% (adult and pediatric
mode)
SpO
2
+ 5 (neonate mode)
ETCO
2
ETCO
2
 0 mmHg
ETCO
2
 2.0 (% or kPa)
ETCO
2
- 5 mmHg
(min. 15 mmHg)
ETCO
2
- 0.7 (% or kPa) (min. 2.0%
or 2.0 kPa)
ETCO
2
+ 10 mmHg
ETCO
2
+ 1.4 (% or kPa)
INCO
2
INCO
2
 0 mmHg
INCO
2
 0 (% or kPa)
Not affected by STAT SET INCO
2
+ 5 mmHg
INCO
2
+ 0.7 (% or kPa)
Apnea Delay Not affected by STAT SET
