120 Specifications Welch Allyn Propaq Encore Vital Signs Monitor
In-service simulated values
Channel Display Initial value Alternate value
ECG Waveform Normal sinus rhythm, 1mV, Lead II Normal sinus rhythm
ECG Heart Rate 80 beats per minute 125 beats per minute
RESP Respiration Rate 12 breaths/minute 31 breaths/minute
P1 Waveform Arterial Same as Initial Value
P1 Pulse Rate 80 pulses per min 125 pulses per min
P1 Systolic 121 mmHg 120 mmHg
P1 Diastolic 79 mmHg 85 mmHg
P1 Mean 96 mmHg 103 mmHg
P2 Waveform Pulmonary Artery Same as Initial Value
P2 Pulse Rate 80 pulses per min 125 pulses per min
P2 Systolic 25 mmHg 25 mmHg
P2 Diastolic 9 mmHg 12 mmHg
P2 Mean 15 mmHg 18 mmHg
NIBP Mode Manual (Auto cancels in-service) Same as Initial Value
NIBP Numerics Actual values from patient Actual values from patient
T1 Numeric 37.0° C 39.1° C
T2 Numeric 36.4° C 37.4° C
T
Numeric 0.6° C 1.7° C
SpO
2
Waveform Normal, 2x Same as Initial Value
SpO
2
Rate 80 pulses per min 125 pulses per min
SpO
2
Numeric 97% 88%
CO
2
Waveform Normal Hyperventilating
CO
2
ETCO
2
Numeric 38 mmHg 60 mmHg
CO
2
INCO
2
Numeric 0 mmHg 8 mmHg
CO
2
Breath Rate 12 breaths/minute 31 breaths/minute
