60 Patient monitoring Welch Allyn Propaq Encore Vital Signs Monitor
Sidestream CO
2
menu and status window
When sidestream CO
2
is active, press MORE from the first CO
2
menu to access the
SCO
2
menu and the SCO
2
status window:
SOURCE Changes between mainstream CO
2
and sidestream CO
2
monitoring
(if both options are installed), or disables CO
2
monitoring
Setting CO2 SOURCE to OFF allows you to disable CO
2
monitoring
without removing the sensor. When the CO2 SOURCE is set to OFF,
the Propaq displays OFF for CO
2
numerics.
SWEEP SPEED The CO
2
and RESP display sweep speed (set by the mm/s button)
BAROMETER The ambient barometric pressure
Note To change CO
2
units, use the Settings Menu under the Service Menus. Changing
these units will clear CO
2
trends.
GAS COMP Selects the measurement compensation for CO
2
measurements
RESPONSE Sets the response time for CO
2
measurement (NORMAL, FAST, OR
SLOW)
SOURCE Changes between mainstream CO
2
and sidestream CO
2
monitoring
(if both options are installed), or disables CO
2
monitoring
Setting CO2 SOURCE to OFF allows you to disable CO
2
monitoring
without removing the sensor. When the CO2 SOURCE is set to OFF,
the Propaq displays OFF for CO
2
numerics.
SWEEP SPEED The CO
2
and RESP display sweep speed (set by the mm/s button)
BAROMETER The ambient barometric pressure
FLOWRATE Sets the sampling flow rate to either 90 or 175 ml/min. You can
change the flow rate while sidestream CO
2
is active
Note To change CO
2
units, use the Settings Menu under the Service Menus. Changing
these units will clear CO
2
trends.
mmHg
GAS COMP PREV MENU RESPONSE
SCO 2 BR
SpO 2
PA
CO 2
GAS COMPENSATION: OFF
RESPONSE : NORMAL
CO2 SOURCE : SIDESTREAM
SWEEP SPEED : 6.25 mm/s
BAROMETER : 762.0 mmHg 35/ 18
( 85)
35 12
92
SOURCE
FLOWRATE : 175 ml/min
FLOWRATE
