Item Specification
6x2-5.0s @ 25 mm/s
6x2-5.0s @ 50 mm/s
12x1-10.0s @ 25 mm/s
Report formats, internal printer,
Average
3x4+3R @ 25 mm/s
3x4+3R @ 50 mm/s
6x2+1R @ 25 mm/s
6x2+1R @ 50 mm/s
No print
ECG storage (in test directory) At least 100 ECG tests
Patient storage Up to 50 patients
Frequency range 0.3 to 150 Hz
Digital sampling rate > 1,000 samples/second/channel
Pacemaker detection ANSI/AAMI EC11
Power requirement Universal AC power supply 110-240 V~, 50/60 Hz ~, 1.5 A maximum
AC fuses Time-lag type, 2.0-amp 250-V rating, Littelfuse 0218002P or equivalent
Rechargeable battery 9 cells
Rating 10.8 V 6.75Ah (73Wh)
Composition Lithium-ion
Recharge time to 100 percent
capacity
4 hrs
Full charge capacity 25 ECG tests @ 20 minutes per test
8 hrs of continuous operation or 250 continuous ECGs
Filters
High-performance baseline 0.5 Hz
Muscle tremor 35 Hz
AC interference 50 Hz or 60 Hz
Safety, EMC, and regulatory
compliance
ANSI/AAMI EC11**
CAN/CSA C22.2 No. 601.1
CAN/CSA C22.2 No. 601.1.2 IEC/EN 60601-1
IEC/EN 60601-1-2
IEC/EN 60601-1-4
50 Specifications CP 150 12-lead resting electrocardiograph
