42

General Duct Recommendation

Support the flexible duct often to prevent sags or bends.

Stretch the duct to make for a smoother interior with less air resistance.

For a 90-degree bend, insert a metal elbow inside the flexible duct to avoid crimping.

Do not squeeze or reduce the inside diameter of the ducts. This restricts the

airflow.

Use short and straight ductwork.

Review the configuration schematic on the Overview Sketch on page 12 for

information about which panels are available for duct connections and service.

Remove the panels or grilles from the openings to connect the ductwork.

Check that all the fan blades move freely.

Check for loose foreign objects in any of the air paths.

Connect the round flexible ducts to the Wine Guardian using the duct collars that are

provided with the duct accessory kit.

Pull the outer plastic wrapping and insulation away from the end of the duct to

expose the reinforced inside duct liner.

Use tie straps of clamp around the

inside liner

to fasten the duct collar.

Do not clamp around the outside insulation. It compresses and loosens over time.

Secure the duct collar to the unit using the screws provided. Be careful not to damage or

bend the gasket.

Using Ductwork

Cold Air to/from Wine Cellar

Connect the supply air ductwork from the cellar to the supply air duct collar at the

Wine Guardian unit.

Connect the return air ductwork from the cellar to the return air duct collar at the

Wine Guardian unit.

Warm Air to/from Condenser

Connect ductwork on the condenser to direct heat and the air noise away from occupants.

Connect ductwork to another space within the basement or to the outdoors if the heat being

exhausted is undesirable.
