Vetter Pipe and Test Sealing Bags
Page 30/33
Technical Data
Egg Profile Testing
and Bypass bags
Pipe cross-
section
mm / inch
Cylinder
length
mm / inch
Total length
mm / inch
Air
requirement
litres / cu. ft.
Weight,
approx.
kg / lbs
EPK 35/52.5 - 50/75
1421000101 1 x 1“ AG
1.5 bar
(21.75 psi)
350/525 - 500/750
14/21 - 20/30
600
23.4
645
25.4
225
7.9
12
26.5
EPK 60/90
1421001300 1 x 2“ AG
1421001200 2 x 2“ AG
1 bar
(14.5 psi)
600/900
23.4/35
1,200
47.2
1,400
55.1
820
29
26 - 35
57.3 - 77.2
EPK 70/105
1421001700 1 x 2“ AG
1421001600 2 x 2“ AG
1 bar
(14.5 psi)
700/1,050
28/41
1,200
47.2
1,450
57.1
1,380
48.7
29 - 38
63.9 - 83.8
EPK 90/135
1421002000 1 x 2“ AG
1421001900 2 x 2“ AG
1 bar
(14.5 psi)
900/1,350
35/53
1,800
70.2
2,200
86.6
2,620
92.5
36 - 46
79.4 - 101.4
Standard test counterpressure of 5 m WC / 7.25 psi
All rights reserved for technical changes within the scope of product improvement.
