Vetter Pipe and Test Sealing Bags - Manual (Page 19)

Page 19/33
Technical data
Pipe Sealing Bags
Pipe
diameter
mm / inch
Diameter
mm / inch
Cylinder
length
mm / inch
Total length
mm / inch
Air
requirement
litres / cu. ft.
Weight,
approx.
kg / lbs
RDK 2.5/4
1440000101
2.5 bar
(36.25 psi)
25 - 40
0.98 - 1.6
21
0.9
115
4.5
175
7
0.7
0.02
0.15
0.33
RDK 4/7
1440000201
2.5 bar
(36.25 psi)
40 - 70
1.6 - 2.8
37
1.5
155
6.1
215
8.5
2.5
0.09
0.2
0.44
RDK 7/15
1440000301
2.5 bar
(36.25 psi)
70 - 150
2.8 - 5.9
68
2.7
300
12
345
13.6
13.3
0.47
0.5
1.1
RDK 10/20
1440011700
2.5 bar
(36.25 psi)
100 - 200
3.9 - 7.8
90
3.5
510
20
555
21.9
40.3
1.4
1.2
2.7
RDK 15/30
1440000601
2.5 bar
(36.25 psi)
150 - 300
5.9 - 11.8
145
5.7
460
18.1
505
20
87.5
3.1
1.9
4.2
RDK 20/40
1440020100
2.5 bar
(36.25 psi)
200 - 400
7.8 - 16
195
7.7
650
25.6
700
27.3
224
7.9
2.8
6.2
RDK 20/50
1440016700
2.5 bar
(36.25 psi)
200 - 500
7.8 - 20
195
7.7
750
29.3
795
31
329.0
11.6
5
11
RDK 30/60
1440000801
2.5 bar
(36.25 psi)
300 - 600
11.8 - 23.4
295
11.6
735
28.9
780
30.7
507.5
17.9
7
15.4
RDK 50/80
1440020000
2.5 bar
(36.25 psi)
500 - 800
20 - 31.5
450
17.7
1,110
43.7
1,155
45.6
2,135
75.4
17
37.5
RDK 60/100
1440011900
2.5 bar
(36.25 psi)
600 - 1,000
23.4 - 39.4
580
22.8
1,320
52
1,365
53,7
3,465
122.3
25
55
RDK 50/100
1480000801
1.5 bar
(21.75 psi)
500 - 1,000
20 - 39.4
450
17.7
1,110
43.7
1,155
45.6
1,525
53.8
17
37.5
RDK 60/120
1480001901
1.5 bar
(21.75 psi)
600 - 1,200
23.4 - 47.2
580
22.8
1,320
52
1,365
53.7
2,475
87.4
25
55
RDK 80/140
1480006000
1.5 bar
(21.75 psi)
800 - 1,400
31.5 - 55.1
785
30.9
1,810
71.3
1,855
73
3,125
110.3
41
90.4
RDK 140/170
1400000300
0.5 bar
(7.25 psi)
1,400 - 1,700
55.1 - 67
1,350
53.2
1,900
74.8
2,150
84.7
8,700
307.1
55
121.3
RDK 170/200
1400000100
0.5 bar
(7.25 psi)
1,700 - 2,000
67 - 78.7
1,620
63.8
1,900
74.8
2,300
90.6
9,000
317.7
59
130.1
RDK 2.5 bar / 36.25 psi - Test counterpressure 10 m WC / 14.50 psi
RDK 1.5 bar / 21.75 psi - Test counterpressure 5 m WC / 7.25 psi
RDK 0.5 bar / 7.25 psi - Test counterpressure 2 m WC / 2.90 psi
All rights reserved for technical changes within the scope of product improvement.
