Vetter Pipe and Test Sealing Bags - Manual (Page 21)

Page 21/33
Technical Data
Test Sealing Bags
Pipe
diameter
mm / inch
Diameter
mm / inch
Cylinder
length
mm / inch
Total length
mm / inch
Air
requirement
litres / cu. ft.
Weight,
approx.
kg / lbs
PDK 7/15 FLEX
1441001201 1 x 1/2“ AG
2.5 bar
(36.25 psi)
70 - 150
2.8 - 5.9
68
2.7
350
13.7
395
15.4
14
0.5
1.7
3.8
PDK 10/20 FLEX
1441018501 1 x 1“ AG
2.5 bar
(36.25 psi)
100 - 200
3.9 - 7.8
90
3.5
510
20
555
21.9
40.3
1.4
2.8
6.2
PDK 15/30 FLEX
1441022700 2 x 1/2“ AG
1441022800 1 x 2“ AG
2.5 bar
(36.25 psi)
150 - 300
5.9 - 11.8
145
5.7
460
18.1
505
20
87.5
3.1
5.8
12.8
PDK 20/40 FLEX
1441040300 2 x 1“ AG
1441018600 1 x 2“ AG
2.5 bar
(36.25 psi)
200 - 400
7.8 - 16
195
7.7
640
25
685
26.7
225
7.9
8
17.6
PDK 20/50 FLEX
1441031100 2 x 1“ AG
1441031200 1 x 2“ AG
2.5 bar
(36.25 psi)
200 - 500
7.8 - 20
195
7.7
750
29.3
795
31
333
11.8
7 - 9
15.4 - 19.8
PDK 30/60 FLEX
1441023100 2 x 1“ AG
1441018701 1 x 2“ AG
2.5 bar
(36.25 psi)
300 - 600
11.8 - 23.4
295
11.6
735
28.9
815
32.1
471
16.6
11 - 12
24.3 - 26.5
PDK 50/80 FLEX
1441003900 1 x 2“ AG
1441003800 2 x 2“ AG
2.5 bar
(36.25 psi)
500 - 800
20 - 31.5
450
17.7
1,110
43.7
1,155
45.6
2,065 - 2,135
72.9 - 75.4
27 - 36
59.5 - 79.4
PDK 60/100 FLEX
1441023200 1 x 2“ AG
1441023300 2 x 2“ AG
2.5 bar
(36.25 psi)
600 - 1,000
23.4 - 39.4
580
22.8
1,320
52
1,365
53.7
3,395 - 3,430
119.8 - 121.1
33.5 - 42
73.9 - 92.6
PDK 50/100 FLEX
1481003501 1 x 2“ AG
1481023800 2 x 2“ AG
1.5 bar
(21.75 psi)
500 - 1,000
20 - 39.4
450
17.7
1,110
43.7
1,155
45.6
1,475 - 1,525
52.1 - 53.8
27 - 36
59.5 - 79.4
PDK 60/120 FLEX
1481009501 1 x 2“ AG
1481009301 2 x 2“ AG
1.5 bar
(21.75 psi)
600 - 1,200
23.4 - 47.2
580
22.8
1,320
52
1,365
53.7
2,425 - 2,450
85.6 - 86.5
33.5 - 42
73.9 - 92.6
PDK 80/140 FLEX
1481024000 1 x 2“ AG
1481023900 2 x 2“ AG
1.5 bar
(21.75 psi)
800 - 1,400
31.5 - 55.1
785
30.9
1,810
71.3
1,855
73
3,075 - 3,100
108.5 - 109.4
55 - 69
121.3 - 152.2
PDK 140/170 FLEX
1401000400 1 x 2“ AG
1401000300 2 x 2“ AG
0.5 bar
(7.25 psi)
1,400 - 1,700
55.1 - 67
1,350
53.2
1,900
74.8
2,150
84.7
8,670 - 8,685
306.1 - 306.6
62.5 - 70
137.8 - 154.4
PDK 170/200 FLEX
1401000700 1 x 2“ AG
1401000600 2 x 2“ AG
0.5 bar
(7.25 psi)
1,700 - 2,000
67 - 78.7
1,620
63.8
1.,00
74.8
2,300
90.6
8,775 - 8,888
309.8 - 313.8
64.5 - 70
142.2 - 154.4
PDK 2.5 bar / 36.25 psi - Test counterpressure 10 m WC / 14.50 psi
PDK 1.5 bar / 21.75 psi - Test counterpressure 5 m WC / 7.25 psi
PDK 0.5 bar / 7.25 psi - Test counterpressure 2 m WC / 2.90 psi
All rights reserved for technical changes within the scope of product improvement.
