Adit Connections
The following illustrations show all connectors on the Adit 3104.
(1) 10/100Base-T
Ethernet (WAN)
(4) 10/100Base-T
Ethernet (LAN)
Tip & Ring Telco
Connector
Alarm
Status
Reset
RS-232
Management
Port
Power/Battery/Status
Ground
Back
Front
(1) DS1/E1 (WAN)
(E1-future)
