Instruction Manual - TORBAL AGC Series
9. To enter an ID or a number, use the following keys: 0(NO) to increment a digit, “T” (YES)
to accept and go to the next digit, “Function” to accept the entire setting, and “C” to clear and
start over. To become familiar with entering an ID, refer to the example in Table 7.1.5.9.
To increment and change digits To accept and move to the next digit
Table 7.1.5.9 Example: Setting an ID 54321
Current Display Action to take Key to use Number of depressions Display becomes
- Increment the digit 0(NO) 6 5
5 Accept and go to next digit T(YES) 1 50
50 Increment the digit 0(NO) 4 54
54 Accept and go to next digit T(YES) 1 540
540 Increment the digit 0(NO) 3 543
543 Accept and go to next digit T(YES) 1 5430
5430 Increment the digit 0(NO) 2 5432
5432 Accept and go to next digit T(YES) 1 54320
54320 Increment the digit 0(NO) 1 54321
54321 Accept the entire setting Function 1 --
