Assembly Information
A D I V I S I O N O F T R I M B L E
Hardware Overview
35
Assembly Information
Cables and Connectors
The following are the cables and connectors used in the Micro Developer’s Kit interface
board:
Mating Connectors for Flip Mount
Power-I/O: Molex 52991-0208
RF: Lighthorse LTI-IPXSF66GT-X1 or LTI-IPXSF54GT
Digital Interface
The cable assembly used consists of the following parts:
Note
Pin numbers and assignments are shown in the
Micro Digital Connector Signal
table.
Antennas
The cable assembly used to connect the “external” RP-TNC connectors on the Micro
Devkit to the Micro u.FL connectors consists of the following parts:
