27
16. Set-up and Calibration
The M2000 weigh indicator (integral in the control box) is set-up with all required
parameters when it is shipped with the On-Board System. Common parameters to all
On-Board systems are shown in Table 1. The appropriate parameter values for popular
net capacities are listed in Table 2 and Table 3. Double check that the parameters are
set appropriately for your system. To check the parameters:
1. Enter the calibration mode channel 1 on the M2000 by keying in:
The display will be showing a blinking “PASS” message. This prompts you to enter a
4 digit password. The factory default password is “1111”. This password can be
changed, but it is recommended that the factory default password be kept. You are
now in calibration mode. You will see a "C" flash on the left side of the display while
in calibration mode.
2. Access the individual parameters by typing the parameter number followed by the
SELECT key.
Example:
3. To change a value, while displaying the parameter value type in the desired number
followed by the TARE key.
Example:
4. When finished exit calibration mode by typing 99 and pressing SELECT.
For more information, refer to the M2000 manual included along with this manual.
