KLU Series Universal Weighbars Operator’s Manual

4.0

Parts List

100107

Portable

Pad Upright

Jam Nut

Portable Pad

Bearing Collar

Bearing

Snap Ring

Spacer

Foam Seal

100963

for .X

4KLU

Washer

100609

for 8, 16KLU

Pad

8, 16 KLU Pads Only

Load Cell

.1 1 KLU

54243

Set Screws

Load Pin

Items may not be exactly
as shown

Load Bar
Tube

100547

Bolt for
Load Cell

Load Cell
2 16 KLU

Figure 4-1. For 0.1 - 16 KLU Load Bar Parts
