Rice Lake Farm Bars - KLU Series Universal Weighbars User Manual
Page 11

Table 4-2. For 30, 45, 60 KLU Load Bars
Description
30 KLU
45 KLU
60 KLU
Part #
Part #
Part #
Bearing
101214
128760
101214
128760
101217
127241
Bearing Collar
65203
66203
127834
67203
127837
*Bearing Collar Assembly1
65202
66202
127833
67202
Foam Bearing Seal
101235
126824
101235
126824
101236
126825
Hex Mounting Bolt (Gr. 8)
100700
126999
100700
126999
100700
126999
Liquid-Tite Connector (3/8)
100547
127146
100547
127146
100547
127146
Load Bar Tube (Specify Length)
65206
66206
67206
Load Cell
65201
66201
67201
Load Cell Assembly (Incl. 202)
65200
127824
66200
127831
67200
127836
Load Pin
65209
127829
65209
127829
67209
127848
Load Pin (Removable Pad)
-----
-----
67209R
127849
Load Pin Lock Bolt
100593
127010
100593
127010
100593
127010
Load Pin Spacer
65210
127830
65210
127830
67210
127850
Load Pin Spacer (Removable Pad)
-----
-----
67210R
127851
Load Pin Stop
67214
127852
67214
127852
67214
127852
Pad – Permanent
65207
127826
65207
127826
65207
127826
Pad – Portable
-----
65207P
127828
67207P
127845
Pad – Removable
-----
-----
67207R
127846
Setscrew
100807
126985
100807
126985
100814
126986
Snap Ring
101229
126808
101229
126808
101230
126809
Operators Manual
127469
127469
127469
*Assembly includes: collar, bearing, snap ring, seals and set screws.
