2 key descriptions – Rice Lake MSI-8000 RF Remote Display User Manual
Page 8

4
MSI-8000
Operator’s Manual
1.2 Key Descriptions
POWER
Turns the
MSI-8000
ON and OFF.
When in setup mode, returns to the normal weight/tension display without
storing the changes.
ZERO
Used to zero out residual tension on the link.
When in the setup mode, drops back one menu level.
At the root menu level, stores the changes and returns to tension mode.
TARE
Removes the current load and puts the system in to the NET weight mode.
Programmable to user selectable functions, see Section 3.0.
Default – Peak Hold.
Functions as the ENTER/SELECT key when in setup menus
Programmable to user selectable functions, see Section 3.0.
Default – Display & Function Test
Functions as the scroll key in setup menus
PRINT Key - Defaulted to the Print function.
Note
If the text is discussing a function key, the function key will be displayed
as Fx-YYYYY with the programmed User Key function in italics. F1 and F2
can both be programmed to all available user functions.
If a function key does not work, it is probably because the connected Scale/Dyna-Link
is not setup to support the key. For example, if the Function key is set for TOTAL, you
must also setup the TOTAL mode in the Setup Menu of the target scale.
