0 appendix, 1 troubleshooting, Appendix – Rice Lake MSI-8000 RF Remote Display User Manual
Page 35

Appendix 31
6.0
Appendix
6.1 Troubleshooting
Problem
Possible Cause
Solution
Display is blank
when POWER
button is pressed
Discharged battery
Recharge
Defective battery
Replace (factory replacement only
Defective switch or
circuit board
Requires Authorized Service
Display does not
function properly/
Front panel
buttons do not
function normally/
Scale/Dyna-Link
will not turn off.
Improperly loaded
software
Reinstall software
Faulty Circuit Board
Requires Authorized Service
Loose Connectors
Requires Authorized Service
Scale/Dyna-Link
does not respond
to tension
changes
Out of calibration
Calibrate
Faulty load cell
Replace
Load cell connector
Check connector and wires
Display over
ranges below
100% of capacity
Tared Tension is
added to load to
determine overload
point
Return to gross tension mode
Zero requires
adjustment
Rezero the scale
Too much tension/
load has been zeroed
Rezero the scale
Display drifts
AZM (Auto0) is turned
off
Turn AZM on
Rapid temperature
changes such as
moving the scale from
indoors to outdoors
Wait until the scale temperature has stabilized
Displayed tension
shows large error
Scale not zeroed
before load is lifted
Zero the scale with no load attached
lb/kg units causing
confusion
Select proper units
Requires recalibration
Recalibrate
Table 6-1. Troubleshooting
