Parts list – Rice Lake Intercomp CS 750 - Users Manual User Manual
Page 23
CS750, Users
Rev R, May, 2009
23
Parts List
Item #
QTY
Part #
Description
1
8
600016
8-32 screw
2
1
220135
charging jack nut
3
2
601013
4 pin MTA
4
1
500610
charging end plate
5
1
220135
charging jack
6
1
500619
battery mounting plate
7
1
000095
display board
8
1
000094
A/D board
9
1
500612
left side board mount
10
1
500615
right side board mount
11
4
601002
6-32 nut
12
4
601032
6-32 standoff
13
16
601014
.031 nylon washer
14
20
600008
6-32 screw
15
4
601015
.062 nylon washer
16
4
601018
6-32 standoff
17
1
000066
cal. switch assembly
18
2
600038
.25-20 screw
19
1
500613
500614
top lifting eye assembly (25 lb - 100 lb capacity)
top lifting eye assembly (250 lb - 1K lb capacity)
20
1
500606
housing machine
21
2
501201
endplate
22
1
250087
switch
23
1
label
24
1
250003
CS750 overlay
25
2
330029
o-ring
26
1
601016
grommet
27
1
500608
swivel
28
1
601055
.250 clevis pin
29
1
602009
.25-28 shoulder bolt
30
1
500607
hook
31
1
603000
safety latch
32
1
601056
cotter pin
33
1
500603
500604
loadcell retainer (25 lb - 750 lb capacity CS750)
loadcell retainer (1K lb capacity CS750)
34
2
601006
601008
.250-28 jam nut (25 lb - 100 lb capacity CS750)
.500-20 jam nut (250 lb - 1K lb capacity CS750)
35
1
603056
603031
603030
603055
603057
603058
loadcell (25 lb capacity CS750)
loadcell (50 lb capacity CS750)
loadcell (100 lb capacity CS750)
loadcell (250 lb capacity CS750)
loadcell (500 lb capacity CS 750)
loadcell (1K lb capacity CS750)
36
1
220063
4-pin MTA
37
2
330027
battery holder
38
1
220061
2-pin MTA
