39
Class Item and Parameter Description
0 600 bps
1 1200 bps
2 2400 bps
3 4800 bps
4 9600 bps
bp5
Baud rate
5 19200 bps
0 7 bits, even
1 7 bits, odd
btpr
Data bit, parity bit
2 8 bits, none
0 CR LF Crlf
Terminator
1 CR
CR: ASCII code 0Dh
LF: ASCII code 0Ah
0 A&D standard format
1 DP format
2 KF format
3 MT format
4 NU format
type
Data format
5 CSV format
Refer to “9-6 Description of the Item
“Data Format””.
0 No limit t-Up
Timeout
1 1 second
Selects the wait time to receive a
command.
0 No output
5if
Serial
interface
erCd
AK, Error code
1 Output
AK:ASCII code 06h
mltMLT
Programmable-unit (Multi-unit)
Sets an arbitrary coefficient.
Available only when programmable-
unit mode is selected.
Unit
Unit
Refer to “4. WEIGHING UNITS”.
id
ID number
Refer to “10. ID NUMBER AND GLP REPORT”
0 Normal weighing mode
1 Capacity indicator
apf
Application function
2 Statistical calculation mode
0 Number of data, sum
1
Number of data, sum, maximum,
minimum, average, range
(maximum-minimum)
ap fnc
Application 5taf
Statistical function
mode output items
2
Number of data, sum, maximum,
minimum, average, range
(maximum-minimum), standard
deviation, coefficient of variation
: Factory settings.
Caution
The balance may not transmit the data completely at the specified refresh rate, depending on the
baud rate.
When a refresh rate of 20 times/second is used, set the baud rate to 4800 bps or higher.
