228
Controls in detail
4-zone automatic climate control
Adjusting air distribution
Use the air distribution controls 1 and 7
( ୴ page 222) or ( ୴ page 223) to separate-
ly adjust the air distribution on each side of
the passenger compartment.
The following symbols are located on the
controls:
̈ Turn air distribution controls 1
and 7 ( ୴ page 222) or ( ୴ page 223)
on each side of the passenger compart-
ment to the desired symbol.
The indicator lamp on the correspond-
ing button goes out and the automatic
air distribution is switched off for the
corresponding side. The air distribution
is controlled according to the thumb-
wheel setting.
Opening the cockpit air vent (Canada
only) and center air vents
̈ Turn thumbwheels 1 and 5
( ୴ page 220) upward.
The cockpit air vent 3 and the center
air vents 2 and 4 are open.
Closing the cockpit air vent (Canada
only) and center air vents
̈ Turn thumbwheels 1 and 5
( ୴ page 220) downward.
The cockpit air vent 3 and the center
air vents 2 and 4 are closed.
Opening the side air vents
̈ Turn thumbwheels 8 and a
( ୴ page 220) upward.
The side air vents 7 and b are open.
Closing the side air vents
̈ Turn thumbwheels 8 and a
( ୴ page 220) downward.
The side air vents 7 and b are
closed.
Symbol Function
a Directs air through the cockpit
(Canada only), center, side and
rear passenger compartment
air vents
Z Directs air to the windshield
and through the side air vents
X Directs air into the entire vehi-
cle interior
Y Directs air to the footwells
i You can also turn the air distribution control
to a position between two symbols.
