211
Controls in detail
Dual-zone automatic climate control
Adjusting air distribution
Use air distribution control rocker
switch
5 ( ୴ page 206) or ( ୴ page 207) to
adjust the air distribution.
The following symbols are located in the
display
4 ( ୴ page 206) or ( ୴ page 207):
̈ Use air distribution control rocker
switch
5 ( ୴ page 206) or
( ୴ page 207) until the desired symbol
appears in the display 4 ( ୴ page 206)
or ( ୴ page 207).
The AUTO indicator for automatic air dis-
tribution in the display 4 goes out.
The automatic function for air distribu-
tion is switched off, and air distribution
is controlled according to the desired
setting.
Opening the cockpit air vent (Canada
only) and center air vents
̈ Turn thumbwheels 1 and 5
( ୴ page 204) upward.
The cockpit air vent 3 and the center
air vents 2 and 4 are open.
Symbol Function
b Directs air into the entire
vehicle interior
c Directs air to the windshield,
through the side air vents and
cockpit air vent (Canada only)
Z Directs air to the windshield
and through the side air vents
X Directs air to the windshield,
through the side air vents and
to the footwells
a Directs air through the cockpit
(Canada only), center, side and
rear passenger compartment
air vents
Y Directs air to the footwells
d Directs air to the footwells and
through the side air vents
i The air volume continues to be controlled
according to the indicator in the display 4.
