29
At a glance
Instrument cluster
Item Page
1 Coolant temperature gauge 444
2 Fuel gauge with:
Fuel tank reserve warning
lamp
A High beam headlamp
indicator lamp
- ABS indicator lamp
= SRS indicator lamp
683
403
628
637
3 Parktronic*/Park Assist*
warning indicator for left
front area
474,
479
4 Multifunction display with:
Speedometer
0
USA only
!
Canada only Electronic
parking brake
warning or indi-
cator lamps 630
Item Page
;
USA only
3
Canada only Brake warning
lamp 629
< Seat belt telltale 635
H Combination low tire
pressure/TPMS mal-
function telltale, USA
only
Low tire pressure*
telltale, Canada only
638
L Left turn signal
indicator lamp
420
K Right turn signal
indicator lamp
420
v ESP ® warning lamp 634
l Distance warning
lamp* 1
79,
454,
634
1 Vehicles without DISTRONIC Plus*: Warning lamp
without function. It illuminates when the ignition is
on. It should go out when the engine is running.
Item Page
5 Parktronic*/Park Assist*
warning indicator for right
front area
474,
479
6 Gear position/range
indicator
435
7 Tachometer with:
± Engine malfunction
indicator lamp
632
8 Selected program mode indi-
cator
437
9 Main menu for control sys-
tem, multifunction display
287
a Outside temperature 445
b Display with:
Additional speedometer 306
: PRE-SAFE ® Brake*
indicator
303
