La-Z-Boy La-Z-Touch Massage System prior to 10/18/2010 - Manual (Page 11)

Reclina-Rocker ® or Reclina-Way ® Chair.
-- Risk of injur y.
• Provide a clear path for operation of the chair, back, and legrest.
Place ta bles and area r ugs at a distance to allow the legrest to fully
extend without r ubbing or interference.
• To safely exit the unit and prevent a tripping hazard bring the back upright
and close the legrest.
NOTICE:
Risk of damage.
• Damage may occur to the mechanism if the legrest is forced closed from the 1st
or 2nd position. The legrest must be extended to the 3rd position and then closed.
To Operate the Legrest
1. Your La-Z-Boy ® reclining chair is equipped with a three-position locking
legrest for customized seating comfor t. Simply pull on the handle rotating it
counterclockwise to control the legrest (F I G U R E 1). You may stop in any one of
three ideal positions . The 1st position is slightly inclined for relaxing reading
(F I G U R E 2). The 2nd position is slightly more inclined for comfor ta ble television
viewing (F I G U R E 3). The 3rd position is fully extended for complete relaxation
(F I G U R E 4). To lower the legrest, rotate the handle counterclockwise to the fully
extended position, then rotate clockwise to the fully closed position.
2. Reclining the chair back is independent of the operation of the legrest. The chair
back can be reclined with the legrest closed or extended. To recline, a pply
pressure to the back. Sit upright to return the back to an upright position.
3. Br ing the back upr ight and close the legrest before getting out of the unit.
Additional Feature on Selected Styles
The chair body can be tilted back w hen the legrest is in use. Shifting your body
weight rearward will cause the chair body to tilt backward offer ing a number of
different positions .
3-Position Legrest Operating Instr uctions:
F I G U R E 1
F I G U R E 3
F I G U R E 2
F I G U R E 4
CLOSED
POSITION
1ST POSITION
2ND POSITION 3RD POSITION
21 20
-- Risk of injur y.
• Provide a clear path for operation of the chair, back, and legrest.
Place ta bles and area r ugs at a distance to allow the legrest to fully
extend without r ubbing or interference.
Furniture Placement
To place your reclining unit the proper distance from the wall, fully recline the unit
leaving a minimum of 2" of space between the top of the back and the wall
(F I G U R E 1).
Make sure tables and other items are at a safe distance to avoid interference
with the operation of the legrest. Improper placement of a table could cause the
occupant to become trapped in the seat (F I G U R E 2). There must be enough
clearance for the legrest to be fully extended before closing.
Fur niture Placement Guide:
F I G U R E 1
F I G U R E 2
WARNING WARNING
