MSM-LP / BIOS Operation
www.kontron.com 31
6 BIOS Operation
The module is equipped with the AMI Aptio ® BIOS located in an onboard SPI serial flash memory. The BIOS can be
updated using a flash utility.
6.1 Determining the BIOS Version
The AMI Aptio ® BIOS version can be determined on the BIOS setup screen.
6.2 Setup Guide
System behavior can be modified by changing the BIOS configuration.
Note: Selecting incorrect values may cause system boot failure. To recover, press < F3> to load setup default values.
6.2.1 Start the AMI Aptio ® BIOS Setup Utility
To start the AMI Aptio ® BIOS setup utility, press < DEL> during boot-up.
Press to enter setup.
The Main Menu then appears.
The Setup Screen is composed of several sections:
Setup Screen Location Function
Menu Bar Top Lists and selects all top level menus.
Legend Bar Bottom right Lists Setup navigation keys.
Item-Specific Help Window Top right Help for the selected item.
Menu Window Center left Selection fields for the current menu.
Temporary Boot Menu
By pressing the < F7> key at the beginning of the startup process the temporary boot menu will appear.
