KTD-S0044-G Page
5 Specifications
KTT20/pITX User's Guide
Onchip Graphics Processing Unit (GPU)
S
Ultra low power GPU up to 333 MHz internal clock and 8 cores
S
Two independent display controllers support 2D/3D graphics rendering
S
720p Video Encode Processor to deliver HD video streams
S
OpenGL
®
ES 2.0 support
S
DVI
®
interface (max. 1920x1080 pixel)
S
Low Voltage Differential Signaling (LVDS) flatpanel interface supports 18/24 bit color depth
with a maximal resolution of 1680x1050 pixel (only single channel possible)
S
Full hardware acceleration of following video decode standards: H.264, MPEG4 and VC1
Onchip Audio Subsystem
S
Codec interface realize the Inter-IC Sound (I
2
S) specification
S
The audio codec supports a maximal resolution of 24 bit with 96 kHz sample rate
Onchip SD/MMC Controller
S
Only 4 bit data bus width
S
Supports FIFO and DMA mode access
S
Supports SDMEM/SDIO specification V2.0 up to 50/25 MHz interface speed
S
Supports MMC specification V4.3 up to 52 MHz interface speed
S
Supports CE-ATA Digital Protocol specification V1.1 up to 52 MHz interface speed
S
Supports eSD specification V2.1
S
Supports e.MMC devices
Fast Ethernet (USB connection): SMSC
®
LAN9514
S
Fully compliant with IEEE802.3
®
/802.3u
®
S
Supports 10BASE-T and 100BASE-TX
S
Full and half duplex mode with flow control
USB Hub (USB connection): SMSC
®
LAN9514
S
Four additional USB 2.0 (EHCI) ports
S
Supports USB 1.1 low and full speed devices
Temperature Monitoring (I
2
C
TM
connection): ADT7461A
S
One onchip thermal sensor and one remote temperature sensor (SoC)
