KTD-S0044-G Page 7 Specifications
KTT20/pITX User's Guide
3.3 Mechanical Specifications
Dimensions
³
Pico-ITX TM form factor 100 x 72 mm ±0.2 mm (complete with all connectors 100 x 79 mm)
³
Height approx. 23 mm
3.4 Electrical Specifications
Supply Voltage
³
5V DC ± 5%
Supply Voltage Ripple
³
Maximum 100mV peak to peak 0 – 20 MHz
Supply Current (Linux ® )
The power consumption test uses a tool to stress the CPU (100% load) and at the same time another tool to
generate a high graphic throughput. The boards were tested with a DVI
® monitor (SXGA resolution), USB
keyboard & mouse and a 16 GByte USB key as boot device.
Variant: 512 MB SDRAM Variant: 1 GB SDRAM
Full Load Idle Deep Sleep Full Load Idle Deep Sleep
[A] [W] [A] [W] [A] [W] [A] [W] [A] [W] [A] [W]
tbd. tbd. tbd. tbd. tbd. tbd. tbd. tbd. 0.31 3.72 0.07 0.85
