KTD-S0044-G Page 42 Appendix C: Connector Overview
KTT20/pITX User's Guide
Pin
GPIO 1
J1300
External Power
J401
Power Front Header
J900
1 VCC1.8 GND RST_BTN+
2 VCC1.8 GND PWR_BTN+
3 GPIO0 I2C_SDA RST_BTN-
4 GPIO1 I2C_SCL PWR_BTN-
5 GPIO2 RSVD POWER_LED-
6 GPIO3 RSVD RSVD
7 GPIO4 GND POWER_LED+
8 GPIO5 GND RSVD
9 GPIO6 VDD RSVD
10 GPIO7 VCC5 RSVD
11 GPIO8 VDD
12 GPIO9 VCC5
13 GPIO10 VCC_IN
14 GPIO11 VCC5
15 GPIO12 VCC_IN
16 GPIO13 VCC5
17 GPIO14 VCC_IN
18 GPIO15 VCC5
19 GND N.C.
20 GND N.C.
Pin
LAN
J2300
USB Standard
J2301
USB Extension
J1900/J2302/J2303
1 TXD+ VCC5 GND
2 TXD- USB0- USBn+
3 RXD+ USB0+ USBn-
4 GND GND VCC5
5 GND VCC5
6 RXD- USB1-
7 GND USB1+
8 GND GND
Pin
microSD TM Socket
J1401
Serial Ports
J2200 - J2202
Battery
J600
1 DATA2 TXD GND
2 CD / DATA3 RXD VBAT3
3 CMD RTS#
4 VCC3 CTS#
5 CLK GND
6 GND
7 DATA0
8 DATA1
