Software Setup
94 AT8060
www.kontron.com
5.1.5.1.2 IOH Configuration sub-menu
CPU Socket 1 DIMM
Information
Subtitle
Node 1 Ch 0 Dimm 0 Display only Memory in the Slot.
Node 1 Ch 1 Dimm 0 Display only Memory in the Slot.
Node 1 Ch 2 Dimm 0 Display only Memory in the Slot.
Node 1 Ch 3 Dimm 0 Display only Memory in the Slot.
Feature Option Description Help text
Intel(R) VT for Directed I/
O Configuration
Selects sub-menu.
Intel(R) VT for Directed
I/O Configuration
Intel(R) I/OAT Disabled, Enabled
Enables/Disables
Intel(R) I/O Acceleration
Technology (I/OAT).
DCA Support Disabled, Enabled
Enables/Disables Direct
Cache Access Support.
VGA Priority Onboard, Offboard
Decides priority between
onboard and 1st
offboard video device
found.
TargetVGA Display Only
TargetVGA from RootPort
under CPU0/CPU1/
CPU2/CPU3
Gen3 Equalization WA's Enabled, Disabled
Support for Gen3
Equalization
Workarounds mentioned
in SNB_BSU Version 0.83
Gen3 Equalization Fail WA Enabled, Disabled
3875734: PCIE: on Gen3
Eq fail, InitFC is
bypassed at Gen1
Gen3 Equalization Phase
2/3 WA
Enabled, Disabled
3875700: PCIe* at 8 GT/s
may not Train Correctly
Equalization Phase 2/3
Supported
Enabled, Disabled
Enable/Disable based
Equalization Phase(2,3)
Supported or Not
Gen3 Equalization
Redoing WA
Enabled, Disabled
3246043: Not sending
EQ TS1 in REC_RCVRLOCK
when redoing
equalization
Feature Option Description Help text
