Functional Description CP382
Page 2 - 8 © 2002 PEP Modular Computers GmbH ID 24208, Rev. 01
Table 2-1: Pinout of the Digital Output Interface Connector CON2
CLUSTER PIN SIGNAL PIN SIGNAL PIN SIGNAL
1 NC 22 NC
2 NC 23 NC 43 NC
3 NC 24 NC 44 NC
4 NC 25 NC 45 NC
5 NC 26 NC 46 NC
6 NC 27 NC 47 NC
CLUSTER C
7 EXTGND_C 28 EXTGND_C 48 EXTRESET_C
8 EXTVCC_C 29 EXTVCC_C 49 EXTVCC_C
9 DOUT_C6 30 DOUT_C7 50 EXTVCC_C
10 DOUT_C3 31 DOUT_C4 51 DOUT_C5
11 DOUT_C0 32 DOUT_C1 52 DOUT_C2
CLUSTER B
12 EXTGND_B 33 EXTGND_B 53 EXTRESET_B
13 EXTVCC_B 34 EXTVCC_B 54 EXTVCC_B
14 DOUT_B6 35 DOUT_B7 55 EXTVCC_B
15 DOUT_B3 36 DOUT_B4 56 DOUT_B5
16 DOUT_B0 37 DOUT_B1 57 DOUT_B2
CLUSTER A
17 EXTGND_A 38 EXTGND_A 58 EXTRESET_A
18 EXTVCC_A 39 EXTVCC_A 59 EXTVCC_A
19 DOUT_A6 40 DOUT_A7 60 EXTVCC_A
20 DOUT_A3 41 DOUT_A4 61 DOUT_A5
21 DOUT_A0 42 DOUT_A1 62 DOUT_A2
