2.
Functional Description
The following sections present more detailed, board level information about the CP382 Digital
Output controller whereby the board components and their basic functionality are discussed in
general.
2.1
General Information
The CP382 is comprised basically of the following:
•
High Side Driver switches
•
Optocouplers
•
DO ProComm controller
•
Controls digital output and provides interfacing to the CompactPCI bus
•
System interfaces for:
•
Front Panel
•
24 channels of digital outputs
•
External supply connection for each cluster
•
External hardware reset for each cluster
•
One 62-pin, female, 3-pin row, D-sub connector (CON2)
•
CompactPCI bus
•
132-pin, female, 6-pin row connector (CON1)
•
CompactPCI specification
•
On board memory: Capability EEPROM (CapROM)
•
Monitor and Control
•
Two operational status LED’s
•
External reset
•
Output failure indicators
•
Software
