GigaPan EPIC Pro - Manual (Page 18)

15
To ensure a steady series of images, use the EPIC Pro with a sturdy tripod fitted with a
standard 1/4-20 or a 3/8-16 tripod screw.
1. Set up the tripod. Ensure that the legs have a solid footing on the ground and that the
tripod is relatively level. If the tripod has a bubble level use it to help level the tripod.
Tighten the adjustment screws on the tripod
2. Remove the tripod quick release plate and attach it to the EPIC Pro’s tripod mount at the
bottom.
3. Gently tighten the screw until the quick release plate is firmly attached to the EPIC Pro.
4. Clip the plate back onto the tripod.
5. Use the bubble level to center and level the EPIC Pro. Adjust the tripod legs and mount as
necessary.
2.3 Mount the EPIC Pro on a tripod
Tripod Mount
Bubble Level
Quick-Release Plate
