Introduction | 9
1.0 Introduction
System Description
The ETS-Lindgren HI-6113 Laser Data Interface and Field Probe
Measurement System consists of:
 HI-61XX Series Field Probe
 HI-6113 Laser Data Interface
 Universal input DC power supply
 Fiber optic cables
 ProbeView  Laser software download —To download
ProbeView Laser, see page 23
See Minimum Computer Requirements on page 10 for the computer
specifications required to install and operate the HI-6113.
The HI-61XX Series Field Probe contains a photo-voltaic converter that provides
power to the probe circuitry when sufficient light power is received by the
converter. The light power is generated by a laser in the HI-6113, and is
transmitted to the converter through an optical fiber cable assembly. This duplex
fiber cable is also used for communication between the Field Probe and the
HI-6113.
