Operating Protocols | 43
Appendix B: Operating Protocols
Communication Protocol
Data Type: RS-232 Serial
Data Mode: Asynchronous
Word Length: 8 bit
Parity: N
Stop Bits: 1
Data Rate: 115,200 baud
Information Transfer Protocol
The HI-61XX Series Field Probe responds to commands from another device; it
transmits no data without first receiving instructions to do so.
C OMMAND S TRUCTURE
See the following pages for detailed information regarding the command
structure to the Field Probe. When the Field Probe completes the command, it
responds with a string consisting of:
 A start character (":")
 The command letter
 Data (if required)
 (a carriage return)
If the command does not require the probe to return any data, the probe simply
responds with the start character (":") then the command letter and a carriage
return. If an error occurs, the Field Probe responds with an error code.
