6
Installation Procedure
Removing the Front Panel Assembly
Disconnect power and all cables from your K3.
Remove the nine screws to free the top cover as shown in Figure 1. After the cover is open, lift it gently to
reach the speaker wire connector. Unplug the speaker then set the top cover aside in a safe place.
Whenever you remove screws from a panel, if one screw seems too tight to loosen
without damaging it, first loosen the other screws then try again. Sometimes one screw
binds in its hole when the other screws are tightened.
Figure 1. Removing K3 Top Cover.
CAUTION: Touch an unpainted metal ground or wear a grounded wrist strap
before touching components or circuit boards inside the K3. See Preventing ESD Damage on
page 4 for more information.
Stand the K3 on its side feet, remove the seven screws shown in Figure 2 and lift the left side panel off. Set
the side panel aside in a safe place to avoid scratches.
Figure 2. Removing the Left Side Panel.
