Elecraft KIO2 User Manual
Page 10
10
Table 4 SW command values for emulation of two-switch combinations.
Function
Switch Combination
FINE RIT on/off
XFIL
RIT
33
Direct Freq. Entry
BAND+
BAND-
34
Fwd/Refl Power
DISPLAY
TUNE
35
AGC on/off
AGC
PRE/ATTN
36
XFIL/AFIL status
XFIL
AGC
37
notch fil. on/off
AFIL
SPLIT
80
noise red. on/off
AFIL
REC
81
Table 5 SW command values for menu entry selection.
Primary Menu
Secondary Menu
Entry
Entry
Entry
Entry
ST L
38
LCD
46
SLCH
54
RTC
62
ST P
39
GRPH
47
RATES
55
RIT
63
T-R
40
OPT
48
DOT
56
ACC
64
INP
41
ATU
49
FPLY
57
AT2
65
RPT
42
RANT
50
PORT
58
PA
66
IAB
43
CAL
51
SPLT
59
TRN1
67
SSBA
44
PF1
52
Po28
60
TRN2
68
SSBC
45
PF2
53
RTTY
61
TRN3
69
UP (Move VFO or Menu Entry/Parameter Up; SET only)
See DN.
TQ (Transmit Query; GET only)
RSP format: TQ0 (receive mode) or TQ1 (transmit mode). This is the preferred way to check RX/TX status since
it requires far fewer bytes than an IF response.
TX (Transmit Mode; SET only)
SET format: TX; (no data). Used to initiate transmit (in SSB and RTTY modes only) by pulling PTT low. Use the
RX command to cancel TX. RX/TX status read is available in the IF response.
XT (XIT Control; GET/SET)
SET/RSP format: XTn; where n is 0 (XIT OFF) or 1 (XIT ON).
