2
Parts Inventory
The table below lists all parts in the kit. Refer to the K2 manual parts lists for photographs.
Ref. Description Part No. Qty
BT1 Battery, 3V lithium, 20 mm dia., CR2032 or equivalent E980039 1
C19 Capacitor, 33 pF ("33" or "330") E530064 1
C9, C15, C16 Capacitor, 470 pF ("471") E530080 3
C11, C14 Capacitor, .01 µF ("103"), 0.1" lead spacing E530019 2
C3, C4, C7, C8 Capacitor, .01 µF ("103"), 0.2" lead spacing E530009 4
C5, C6 Capacitor, .022 µF ("223") E530056 2
C1, C2 Capacitor, .068 µF ("683") E530081 2
C12, C13, C17, C18 Capacitor, 0.22 µF ("224") E530079 4
C10 Capacitor, electrolytic, 10 µF E530045 1
D1, D2 Diode, 1N5711 E560004 2
CTRL -J1 Conn., 5 pin female, 0.1" spcg., gold E620051 1
CTRL -J2 Conn., 3 pin female, 0.1" spcg., gold E620009 1
L1, L2 Inductor, 82 mH, 5%, shielded ("823") E690015 2
P1 Conn., 5-pin male, 0.1" spcg., gold E620052 1
P2 Conn., 3-pin male, 0.1" spcg., gold E620053 1
Q1, Q2, Q3 Transistor, J309 JFET E580009 3
R11, R12, R15-R17 Resistor, 220 ohms, 1/4 watt, 5% (red-red-brown) E500002 5
R3, R7 Resistor, 470 ohms, 1/4 watt, 5% (yellow-violet-brown) E500003 2
R13 Resistor, 910 ohms, 1/4 watt, 5% (white-brown-brown ) E500070 1
R14 Resistor, 2.7 k, 1/4 watt, 5% (red-violet-red) E500005 1
R9, R10 Resistor, 10 k, 1/4 watt, 5% (brown-black-orange) E500015 2
R4 Resistor, 47 k, 1/4 watt, 5% (yellow-violet-orange) E500067 1
R5 Resistor, 100 k, 1/4 watt, 5% (brown-black-yellow) E500006 1
R6 Resistor, 180 k, 1/4 watt, 5% (brown-gray-yellow) E500068 1
R8 Resistor, 510 k, 1/4 watt, 5% (green-brown-yellow) E500069 1
R1, R2 Trimmer potentiometer, 5K ("502") E520009 2
RP1 Resistor network, 3.9 k, 4 resistors, 8 pins E510000 1
S1 Miniature slide switch, DPDT E640009 1
U1 IC, quad low-noise op-amp, LM837N E600037 1
U2 IC, programmed microcontroller, PIC16C621A-04/P E610009 1
U3 IC, real-time clock, NJU6355ED E600038 1
U4 IC, voltage regulator, 6V, 2.5%, ZR78L06C E600017 1
W1 Conn., 2-pin male, 0.1" spacing E620054 1
X1 Crystal, cylindrical, 32.768 kHz E660015 1
Z1 Ceramic resonator, 4 MHz, 3 pins E660001 1
MISC Jumper, 2-pin shorting (for W1) E620031 1
MISC KAF2 PC board E100128 1
MISC Socket for BT1 E980040 1
MISC IC socket (for U2), 18 pins E620031 1
HDWR Standoff, male-female, 1/2" long x 1/4" dia, 4-40 thd E700057 1
