2
Parts List
Drawing Description Qty Part No.
Lever, spring steel
i
DO NOT FLATTEN OR BEND THE
LEVER. IT IS FABRICATED WITH A
PRECISE AMOUNT OF TENSION AND
CURVATURE.
2 E100182
Grip, molded rubber
i
Do not tear or puncture the grips. Also do
not attempt to clean them. They will have slight
variations in surface texture or color due to the
molding process.
2 E100181
Bracket, aluminum 1 E100177
Thumb screw, captive 1 E100186
Plug, 1/8 th -inch (3.5 mm) stereo
Note: The plug's handle will not be used.
1 E620070
Silver wire, #24 solid, bare 2" E760024
PC Board, KXPD1 2 E100176
Lock Washer, #4 (2 spares) 6 E700004
Screw, 4-40 x 3/16" (4.8 mm) pan-head (2 spares) 6 E700015
Hookup wire, #24 solid, insulated 1 ft. E760008
Hole Cover Label 1 E980096
Washer, Flat, Stainless Steel, 0.010 Thick, #6 1 E700117
Lock Washer, Internal Tooth, #6 1 E700095
