EFCO 6/2012

Page 6

Series 526 Impact Installation Instructions

KP01

Head & Horizontal

Shear Block Package

Use With 16H2 & 16G2

K876

Door Header

Shear Block Package

Use With 16H4 & 16H5

KP04

Shear Block Package

With Shim for

Horizontal Thru

Use With 16K6

KP03

Shear Block Package

for Horizontal Thru

Use With 16K6

SECTION II: Parts Identification Chart

Shear Blocks:










Setting Blocks:







Glazing Gasket:




Weather Seal:




HEP0

Sill & Horizontal

Setting Blocks

HN13

Door Header

Setting Block

W138

Door Stop

Weather Seal

W146

Dry Glazed

Preset Gasket

W167

Drive-In Glazing

Gasket

WEQ1

Structural Glazed

Preset Gasket
