SECTION II - PARTS IDENTIFICATION CHART
K905
K904
K901
K900
DPS 1/2004
PAGE 6
(CONT.)
PART NO. DESCRIPTION
MISC. PARTS
SHAPES ON THIS PAGE ARE NOT TO SCALE
PART NO.
K999
KN04
KN05
K968
BACKER PLATE & SHIM
PACKAGE FOR 180/MP1
TOP PIVOTS
LEFT HAND MP2/195
BOTTOM PIVOT BACKER
PACKAGE
RIGHT HAND MP2/195
BOTTOM PIVOT BACKER
PACKAGE
DOOR JAMB MOUNTING
PLATE & SPACER PKG.
FOR M19/MP3 INT. PIVOT
MISC. PARTS
DESCRIPTION
BUTT HINGE BACKER PKG.
FOR 4 1/2 X 4 BUTT HINGES
(CLEAR)
BUTT HINGE BACKER PKG.
FOR 4 1/2 X 4 BUTT HINGES
(BRONZE)
BUTT HINGE BACKER PKG.
FOR 5 X 4 1/2 BUTT HINGES
(CLEAR)
BUTT HINGE BACKER PKG.
FOR 5 X 4 1/2 BUTT HINGES
(BRONZE)
