EFCO 525 Series - Manual (Page 4)

SECTION II - PARTS IDENTIFICATION CHART
SHAPES ON THIS PAGE ARE NOT TO SCALE
VERTICAL MULLION
(Deep Pocket)
-SCREW SPLINE ONLY-
Use with 4481
SUBSILL
Interlocks with 4475 sill only.
GLAZING BEAD
Use with 4475 and 4491.
SILL
Interlocks with 4482
subsill only.
Use with 4485 stop
INTERMEDIATE
HORIZONTAL
HORIZONTALS
VERTICAL MULLION FILLER
(Shallow Pocket)
-SCREW SPLINE ONLY-
Use with 4480
HEAD
4482
4485
4475
4491
4479
4481
4480
VERTICAL MULLION
-SHEAR BLOCK ONLY-
VERTICALS
PERIMETER JAMB
-SHEAR BLOCK OR
SCREW SPLINE-
DESCRIPTION
4477
PART NO.
4476
9914
9155
4437
4488
4487
4486
4483
DOOR STOP COVER
Use with 4437 door stop at 4478
door jamb.
SLIDE ARM COVER/DOOR
STOP
Use with 4483 C.O.C. door header
DOOR STOP
Use with 9155 door stop cover at
4478 door jamb.
REMOVABLE TRANSOM
GLASS STOP
Use with 4487 glass stop at 4478
door jamb.
FIXED TRANSOM
GLASS STOP
Use with 4488 glass stop at
4478 door jamb.
DOOR HEADER
GLAZING BEAD
Use with 4483 and
4484 door headers.
C.O.C. DOOR HEADER
-SHEAR BLOCK ONLY-
Use with 4486 glazing bead.
4484
4478
PART NO.
STD. DOOR HEADER
-SHEAR BLOCK ONLY-
Uses 4486 glazing bead.
DOOR JAMB
-SHEAR BLOCK ONLY-
Uses 4437/9155 door stop and
4487/4488 transom glass stop.
DOOR FRAMES
DESCRIPTION
PAGE 2
MDM 04/06
4399
DOOR STOP
Use with 9155 door stop cover at
2" doors and 4478 door jamb.
MALE EXPANSION
MULLION
FEMALE EXPANSION
MULLION
16D2
16D1
