EFCO 525 Series - Manual (Page 7)

SECTION II - PARTS IDENTIFICATION CHART
FT16
DPS 3/2004
SUBSILL END DAM
PACKAGE
USED WITH 4482 SUBSILL
KN66
(CONT.)
PART NO.
K492
K495
K936
K496
K990
K987
PART NO.
WM01
HWD1
K874
K873
K875
K435
FT20
DESCRIPTION
REINFORCING PKG.
FOR 1490 PANIC & 3-POINT
LOCK @ THRESHOLD AND
3-POINT LOCK
@ HEAD FOR SINGLE DOOR
REINFORCING PKG. FOR
FLUSH BOLT & 3-POINT
LOCK @ HEAD
FOR PAIR DOORS
MILL COVER PLATE FOR
DORMA RTS 88 C.O.C. AT
BUTTS AND CONT. HINGE
(CUSTOMER SPECIFY FINISH)
COVER PLATE FOR
DORMA RTS 88 C.O.C. AT
BUTTS AND CONT. HINGE
(CLEAR ANODIZE)
COVER PLATE FOR
DORMA RTS 88 C.O.C. AT
BUTTS AND CONT. HINGE
(DRK. BRNZ. ANODIZE)
MISC. PARTS
PAGE 5
MISC. PARTS
DESCRIPTION
BOND BREAKER TAPE
4" X .062"
USED @ SUBSILL SPLICES
WATER DEFLECTOR
@ INT. HORIZONTAL
DORMA RTS-88 C.O.C.
SUPPORT PKG. FOR BUTT
& CONTINUOUS HINGES
RHRB
DORMA RTS-88 C.O.C.
SUPPORT PKG. FOR BUTT
& CONTINUOUS HINGES
LHRB
DORMA RTS-88 C.O.C.
F-CLIP SPACER PKG. FOR
BUTT & CONT. HINGES
ATTACHMENT CLIP FOR
DORMA RTS 88 C.O.C. FOR
OFFSET PIVOTS
RH COVER PLATE FOR
DORMA RTS 88 C.O.C. AT
OFFSET PIVOTS
(CUSTOMER SPECIFY FINISH)
F-CLIP FOR DORMA RTS 88
C.O.C. AT OFFSET PIVOTS
USE FASTENERS SUPPLIED
WITH CLOSER.
FT26
SHAPES ON THIS PAGE ARE NOT TO SCALE
LH COVER PLATE FOR
DORMA RTS 88 C.O.C. AT
OFFSET PIVOTS
(CUSTOMER SPECIFY FINISH)
REINFORCING PKG.
FOR 1490 PANIC
@ THRESHOLD
FOR PAIR DOORS
525 IMPACT
