Pre-Installation Guide for Model 224 and 424 Automotive Dynamometers
D Y N O P R E - I N S T A L L A T I O N I N F O R M A T I O N
In Ground Model 424xLC
2 Dyno
36
Figure 23: In Ground Model 424xLC 2 4WD Dyno with Track Assembly Dimensions
AD406
218.44 cm (86.00 in.)
dyno frame only
321.23 cm (123.47 in.)
frame and brake
130.18 cm (51.25 in.)
frame and cradle assembly
73.66 cm
(29.00 in.)
frame
218.44 cm (86.00 in.)
track
224.15 cm (88.25 in.)
track
