D Y N O P R E - I N S T A L L A T I O N I N F O R M A T I O N
Above Ground Model 424xLC 2 Dyno
Version 5 Pre-Installation Guide for Model 224 and 424 Automotive Dynamometers
29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABOVE GROUND MODEL 424XLC 2 DYNO
The following specifications and requirements will help you set up your dyno area
and verify you have met the requirements necessary to operate your dyno safely.
C HASSIS S PECIFICATIONS
description specifications
Length
of frame 218.44 cm (86.00 in.)
of frame with eddy current brake 321.23 cm (126.47 in.)
of frame with eddy current brake and
Linx option 372.03 cm (146.47 in.)
Height
to top of frame 58.42 cm (23.00 in.)
to top of frame with feet/track
assembly 72.07 cm (28.375 in.)
floor to top of eddy current brake 80.01 cm (31.50 in.)
Width
of frame 73.66 cm (29.00 in.)
including cradle assembly 130.18 cm (51.25 in.)
including air brake 93.83 cm (36.94 in.)
both frames, deck, bridge—full in 388.62 cm (153.00 in.)
both frames, deck, bridge—full in
with extension kit 414.02 cm (163.00 in.)
both frames, deck, bridge—full out 495.30 cm (195.00 in.)
both frames, deck, bridge—full out
with extension kit 520.70 cm (205.00 in.)
Track Assembly
length 218.44 cm (86.00 in.)
width 224.15 cm (88.25 in.)
Weight
stationary crated dyno 2,114 kg (4,660 lb.)
4WD crated dyno 2,495 kg (5,500 lb.)
eddy current brake 635 kg (1400 lb.)
Drum
diameter 60.96 cm (24.00 in.)
width 205.74 cm (81.00 in.)
Frame structural steel channel and angle
Maximum Speed 322 kph (200 mph)
Maximum Axle Weight 1361 kg (3000 lb.)
Remote Switches remote software control
