S P E C I F I C A T I O N S A N D O P E R A T I N G R E Q U I R E M E N T S

Dynamometer Specifications and Requirements

Version 3

In Ground Model 224 4WD Automotive Dynamometer Installation Guide

1-7

E

NVIRONMENTAL

R

EQUIREMENTS

F

IRE

S

UPPRESSION

Always have adequate fire suppression or fire extinguishers in your dyno room.

F

ORKLIFT

R

EQUIREMENTS

You will need to provide equipment capable of lifting 1905 kg (4200 pounds) to lift
the crated dyno and 1588 kg (3500 pounds) to lift the dyno off the crate and into
position in your dyno room. You will also need a pair of straps capable of supporting
1588 kg (3500 pounds) to attach to the dyno. Dynojet recommends using single loop
style straps.

G

ROUND

H

OOKS

The ground hooks allow you to secure your car in place using the tie-down straps.
The layout of the ground hooks is described in the pit dimensions (P/N 98219105)
provided by your salesperson. Refer to Appendix A for Red Head Anchor installation
instructions.

P

HONE

AND

I

NTERNET

A

CCESS

Dynojet recommends you have a phone close to the dyno to call for assistance in an
emergency. You may also wish to contact Dynojet to troubleshoot your dyno.
Internet access on your computer is desirable for contacting Dynojet and
downloading new information and updates.

T

IE

-D

OWN

S

TRAPS

Dynojet recommends using tie-down straps for securing the car on the dyno. The 224
dyno comes with an automotive tie-down package.

description

specifications

Temperature

operating min./max

10°C/50°C (50°F/122°F)

storage min./max

0°C/70°C (32°F/158°F)

Humidity

0 to 95% non condensing
